Introducing the DC Motor Switching Module
Upgrade your control system for various appliances such as garage doors, chicken coop doors, car central locking systems, and more with this versatile DC motor switching module. Designed for ease of use and reliable performance, this module allows you to control your motor's direction effortlessly with simple input signals.
Key Features:
🔁 Polarity Reversal: Easily reverse the polarity of your motor's direction by applying a positive signal to one of the two control inputs. This feature provides flexibility in controlling the movement of your motorized devices.
🔌 Wide Compatibility: Compatible with a range of power inputs, including 1 to 24V DC and 1 to 120V AC, making it suitable for various motor voltage requirements.
⚡ High Power Output: The module offers a robust output of 12V DC at 2A, allowing it to efficiently power motors with a capacity of up to 24 watts, ensuring reliable operation for your applications.
🛡️ Short Circuit Protection: Built-in protection mechanisms safeguard against short circuits when signals are received at both input terminals simultaneously, ensuring the safety and longevity of your equipment.
📏 Compact Design: With compact dimensions of 24mm x 20mm x 15mm, this module is space-efficient and easy to integrate into your existing setup, providing seamless operation without taking up excess space.
How It Works:
Connect the power supply to the input terminals marked "In" using the red and black wires. Ensure correct polarity.
Connect your DC motor to the output terminals marked "OUT" using the white wires.
Apply a 12V+ DC signal to one of the orange wires to start the motor in one direction. The motor will run for the duration of the signal.
To reverse the motor's direction, apply a 12V+ DC signal to the other orange wire. The motor will now run in the opposite direction, with the polarity reversed.
Upgrade your control system with the DC Motor Switching Module and enjoy seamless control over your motorized appliances. Experience versatility, reliability, and ease of use in one compact package. 🛠️🔋
