Introducing the Door Controller: Your Solution for Automated Door Operation
The Door Controller is a versatile device designed to effortlessly manage small 12VDC electric doors, whether it's for your chicken coop, garage, gate, or other applications. With built-in timers and polarity reversal functionality, this controller streamlines the process of opening and closing doors with ease.
Key Features:
🚪 Dual Timer Functionality: The controller features two built-in timers, one for opening and one for closing the door, allowing for precise control over door operation.
↕️ Polarity Reversal: With the ability to reverse polarity, the controller ensures smooth and efficient door movement in both directions, enhancing versatility and functionality.
🟢🔴 LED Indicators: LED indicators provide clear visual feedback on the status of each timer, with green indicating operation in one direction and red in the other direction, allowing for easy monitoring.
🛡️ Built-in Protection: The controller is equipped with built-in protection to safeguard against common pulse inputs, ensuring reliable and safe operation.
🔧 Adjustable Time Settings: Time settings can be easily adjusted using the trimmer, allowing users to customize the duration of door opening and closing according to their specific requirements.
🔌 Easy Installation: The controller is simple to install, with red and black wires for power supply connection and two white wires for motor connection, making setup hassle-free.
Package Contents:
- Door Controller Unit
- Instruction Manual and Wiring Diagram
Principle of Operation:
- Connect the red and black wires to the power supply (min 4A adapter recommended) and the two white wires to the motor (max 2A).
- When Timer 1's orange wire receives a 12V+ pulse, the module activates, supplying 12V to the motor for the set duration of Time 1 before stopping.
- When Timer 2's orange wire receives a 12V+ pulse, the motor receives reverse polarity 12V+, initiating movement in the opposite direction for the set duration of Time 2 before stopping.
Note: If using a 12V- pulse, solder two wires onto the plate and follow the wiring diagram accordingly.
Upgrade your door automation system with the Door Controller and enjoy effortless door operation tailored to your specific needs. Experience convenience, efficiency, and reliability like never before! 🚪🔧
