Enhance your control over electrical devices with our Timer featuring an adjustable delay time from 1 to 150 seconds. Compact and efficient, this timer is perfect for various applications requiring precise timing control.
Dimensions:
📏 Length: 38 mm
📏 Width: 24 mm
📏 Height: 19 mm
Power Supply:
🔋 Voltage Range: 10 to 14 V DC
🔴 Red Wire: 12V+
⚫ Black Wire: 12V-
Output:
⚡ Direct 12V 20A
⚪ White Wire: 12V+
🔵 Blue Wire: 12V-
Key Features:
⏱️ Adjustable Timing: Easily set the delay time from 1 to 10 / 150 seconds using a trimmer and a small screwdriver. Rotate clockwise to increase the time.
💡 LED Indication: The LED lights up when the relay is activated, providing clear visual feedback.
🔒 Safety Fuse: For added safety, you can install a 20A fuse on the red wire.
🔌 Direct Voltage Output: The output provides direct 12V, allowing you to wire the load directly.
Important Notes:
⚠️ The timer will not function if the power supply is below 10V.
❌ Setting the timer to the minimal time may cause the relay to click upon power-up (not recommended).
💪 If your load exceeds 20A, use a separate, more powerful relay after the timer.
Operating Principle:
- Power On: The delay time starts when power is supplied. The LED lights up, and the output (white and blue wires) receives 12V.
- Delay Period: The relay remains activated during the set time.
- End of Cycle: Once the set time elapses, the relay deactivates, and the output stops receiving 12V, even if power is still on.
- Cycle Restart: Restarting the power supply will repeat the cycle.
This timer is housed in a durable plastic box, ensuring longevity and protection.
Package Contents:
📦 Timer
📖 Instruction Manual and Wiring Diagram 1 to 10sec
📖 Instruction Manual and Wiring Diagram 1 to 150sec
📖 Instruction Manual and Wiring Diagram 1 to 480sec
