Introducing the Precision Timer
Upgrade your control systems with our Precision Time Relay, offering accurate timing functionality for various applications. Whether you need precise control over equipment operation or automated switching, this relay delivers reliable performance in a compact form factor.
Key Features:
🕒 Adjustable Timing: Set precise time intervals from 0.3 to 7 / 13 / 50 / 150 / 480 sec seconds using the PR trimmer, allowing tailored control over connected devices.
🔌 Versatile Compatibility: With relay output ratings of 20A/24V DC and 20A/12V DC, this timer is compatible with a wide range of electrical loads and systems.
🔧 Easy Installation: Compact dimensions (27mm x 23mm x 15mm) and simple wiring make installation hassle-free, saving time and effort.
🔒 Reverse Voltage Protection: Built-in protection against reverse supply voltage ensures the safety and longevity of your equipment and electrical systems.
🔄 Reliable Operation: The timer's NO (Normally Open) contact maintains its position when activated, providing stable and consistent operation throughout the set time interval.
📏 Compact Design: Featuring a sleek plate design, this relay offers a space-saving solution without compromising on performance.
Principle of Operation:
Upon power activation, the relay is engaged, and the NO contact (two white wires) closes, maintaining this position for the set time duration.
At the end of the programmed time interval, the relay disengages, and the NO contact returns to its default state.
With power reset, the relay cycle repeats, allowing for continuous and reliable timing control.
Package Contents:
Precision Timer: Includes all necessary components for immediate use and integration into your system.
Instruction Manual and Wiring Diagram: Detailed instructions for seamless setup and configuration, ensuring optimal performance.
Instruction and Wiring Diagram 0.3 to 7 seconds
Instruction and Wiring Diagram 0.3 to 13 seconds
Instruction and Wiring Diagram 0.3 to 25 seconds
Instruction and Wiring Diagram 0.3 to 50 seconds
Instruction and Wiring Diagram 0.3 to 150 seconds
Instruction and Wiring Diagram 0.3 to 480 seconds
Upgrade your control systems with precision timing capabilities using our Precision Time Relay. Experience enhanced automation and efficiency in your applications today! ⏱️🔌
